Introduction of the structural characteristics and application classification of distribution board

Publish Time: Author: Site Editor Visit: 376

Structural characteristics and purpose classification of distribution board:

(1) Fixed panel switchgear

It is called switch board or distribution panel. It is an open switch cabinet with panel blocking. The front has protective effect, and the back and side can still touch the live parts. The protection level is low. It can only be used for industrial and mining enterprises with low requirements for power supply continuity and reliability for centralized power supply in the substation.

(2) Protective (i.e. closed) switchgear

It refers to a low-voltage switchgear with all sides closed except the mounting surface. The switch, protection, monitoring and control and other electrical components of this cabinet are installed in a closed shell made of steel or insulating materials, which can be reliably installed on or off the wall. No isolation measures can be taken between each circuit in the cabinet, or grounded metal plate or insulating plate can be used for isolation. Usually, the door is different from the operation of the main switch Mechanical interlock. In addition, there is a protective desk type switch cabinet (i.e. console), which is equipped with control, measurement, signal and other electrical appliances. The protective switch cabinet is mainly used as the power distribution device on the process site.

(3) Drawer type switch cabinet

This kind of switch cabinet is made of closed shell made of steel plate, and the electrical components of incoming and outgoing circuit are installed in withdrawable drawers to form a functional unit that can complete a certain type of power supply task. Functional units are separated from buses or cables by grounded metal plates or functional plates made of plastic to form three areas of buses, functional units and cables. Isolation measures are also taken between each functional unit. Drawer type switch cabinet has high reliability, safety and interchangeability. It is a relatively advanced switch cabinet. Most of the switch cabinets refer to drawer type switch cabinets. They are applicable to industrial and mining enterprises and high-rise buildings that require high power supply reliability, and serve as centralized control distribution centers.

(4) Power and lighting distribution control box

Mostly closed vertical installation. Due to different use occasions, the protection grade of the shell is also different. They are mainly used as power distribution devices at the production site of industrial and mining enterprises.
