Metal Junction Box Control Desks Electrical Metal Switch Box
- Type:
- DISTRIBUTION BOX
- OEM:
- Offered
- Protection Level:
- IP66
- Color:
- Ral7035 or Ral7032
- Material:
- AISI 304 or AISI 316 Stainless steel
- External Size:
- From 200x200x150mm to 1200x1000x300mm
- Certificate:
- CE,IEC,ROHS,TUV,SGS
- Lock:
- Available On Request
- Thickness:
- 1.2mm,1.5mm,2.0mm
- Paint Finish:
- Epoxy polyester coating
Material :
- Enclosure body & door : AISI 304 or AISI 316 Stainless steel
- Mounting plate : Galvanized steel
- Hinge and lock : Zinc alloy
Thickness:
Body:
- 1.2mm thickness for height from 250mm to 800mm
- 1.5mm thickness for height from 1000mm to 1200mm
Door:
- 1.2mm thickness for height from 250mm to 600mm
- 1.5mm thickness for height from 700mm to 1200mm
Mounting plate:
- 2.0mm thickness for all dimension.
Surface finish:
- Enclosure and door: Polished or Mirror
- Mounting plate:Galvanized
Protection:
- Protection degree:IP66
- Impact resistance:IK10
Supply include:
- Enclosure of all-round solid construction
- Gland plate with sealing gasket,
- Door with lock and key
- Fixing accessories for gland plate
